Heat Resistant 1050g Brown High Silica Fiberglass Fabric Fireproof
High silica fiberglass is a special fiberglass fabric that contains
more than 96% silica (SiO2). With excellent heat resistance, it can
withstand continuous operating temperatures up to 1000°C and peak
temperatures up to 1500°C. It provides excellent spark and slag
protection and is ideal for the aerospace industry, stress relief,
stainless steel welding and equipment protection. It also has
excellent performance in low thermal shrinkage, low thermal
conductivity, electrical insulation, asbestos free and no
pollution.
Data
| Continuous Operating Temp. | 900℃ |
| Highest short exposure temp. | 1450°C work 10 minutes |
| SiO2 Purity | ≥96% |
| Width (mm) | 920mm |
| Rated Voltage | 10KV |
| Structure | blanket is braided of high silica |
| Reactions | Resists most acids, oil & water |
| Clasp and zipper can be added if in need. |
| Design Capabilities | Keep the stable strength and ductility even continuous exposed
under high temperature |
| Application | Widely used in metallurgy, electricity, coal, air and chemical
industrial |
Performance
1. extremely high temperature service performance
2. low thermal shrinkage and low thermal conductivity
3. stable chemical ability
4. good electrical insulation
5. no pollution
Benefits of the feature
1. The softening point is close to 1700oC. It can be used in 900℃
environment for a long time. It can work for 10 minutes at 1450oC
and 15 seconds at 1600oC, and can immediately withstand thousands
of degrees of airflow brush.
2. in organic and inorganic acids (except hydrofluoric acid,
phosphoric acid and hydrochloric acid) can maintain good
performance and stability even in high temperature, weak alkaline
solution.
3. can meet thermal shock and high radiation, high stability,
excellent insulation performance under high temperature and high
humidity conditions, and good adhesion with high temperature
adhesive.
4. resistant to moisture, sunlight and earthquake resistance, can
be used in a variety of sealing materials, structurally strong, to
maintain flexibility under a variety of high temperature
conditions.
5. the structural performance is stable, no harm to the human body,
can replace ceramic fiber and asbestos fiber (phase change occurs
at high temperature crystallization).
6. high temperature and fire resistance, burning in gasoline
without oxidation, no discoloration, high strength, no secondary
pollution.
7. has good wear resistance and insulation.
Application
1. High temperature resistant, insulating, sealing material
2. High temperature ablation material
3. Fireproof materials (fire protective clothing, fire curtains,
fire blankets)
4. Dust removal in high temperature gaseous media and filtration in
high temperature liquid media
5. Molten metal filter
6. Automobile, motorcycle filter, insulation, filtration
7. Welding protective material
8. Electrical insulation material
